🤖 Cisco ACI MCP Server

A stand-alone MCP server built with FastMCP that exposes 50 ACI operations as MCP tools. Connect any MCP-compatible client and LLM to query, provision, and manage your Cisco ACI fabric through natural language.

Overview

This MCP server acts as a lightweight middleware layer between Cisco ACI (Application Centric Infrastructure) and any MCP-compatible client. It allows an LLM to query the ACI fabric, inspect tenants, EPGs, bridge domains, faults, and fabric health — and to create or delete policy objects — all through structured MCP tools.

This is a community based project and is not officially supported by any Cisco Business or Technical entity.

The server communicates with the APIC REST API using cookie-based authentication and supports 50 operations covering the full ACI policy model.

Features

Plug-and-play — works with any MCP-compatible client (VS Code Copilot, Claude Desktop, N8N, etc.)
50 ACI operations — GET and POST across tenants, EPGs, BDs, VRFs, contracts, fabric nodes, and more
Fabric health & faults — query fault summaries, critical faults, and node health in one call
Auto re-authentication — transparently refreshes the APIC session on token expiry
Composite operations — single-tool commands to deploy a full 3-tier application or web stack
No hardcoded credentials — all secrets sourced from a .env file
Fully type-hinted tools for clarity and extensibility

Requirements

Python 3.13+
Access to a Cisco APIC (on-premises or sandbox)
An APIC user with read and/or write privileges

Python dependencies (requirements.txt):

Package	Purpose
`fastmcp`	MCP server framework
`httpx`	Async-capable HTTP client for APIC API calls
`python-dotenv`	Load credentials from `.env`
`pydantic`	Data validation
`requests`	Supplementary HTTP support

Available MCP Tools

Connection & Test (1 tool)

Tool	Description
`aci_simple_test()`	Verify connectivity to the MCP server

Core Infrastructure — GET (12 tools)

Tool	Description
`aci_tenants_get()`	List all tenants
`aci_application_profiles_get()`	List all application profiles
`aci_endpoint_groups_get()`	List all EPGs
`aci_bridge_domains_get()`	List all bridge domains
`aci_contexts_get()`	List all VRFs
`aci_subnets_get()`	List all subnets
`aci_contracts_get()`	List all contracts
`aci_contract_subjects_get()`	List all contract subjects
`aci_filters_get()`	List all filters
`aci_filter_entries_get()`	List all filter entries
`aci_endpoints_get()`	List all learned endpoints
`aci_faults_get()`	List all faults (fault summary)

Fabric & Infrastructure — GET (8 tools)

Tool	Description
`aci_fabric_nodes_get()`	List all fabric nodes (leaves, spines, APICs)
`aci_fabric_health_get()`	Get overall fabric health score
`aci_fabric_links_get()`	List all fabric links
`aci_physical_interfaces_get()`	List all physical interfaces
`aci_ethernet_interfaces_get()`	List all ethernet interface states
`aci_vlan_pools_get()`	List all VLAN pools
`aci_domains_get()`	List all physical domains
`aci_critical_faults_get()`	List only critical-severity faults

Core Policy — CREATE (13 tools)

Tool	Parameters	Description
`aci_tenant_create`	`tenant_name`, `description?`	Create a new tenant
`aci_vrf_create`	`tenant_name`, `vrf_name`, `description?`	Create a VRF
`aci_bridge_domain_create`	`tenant_name`, `vrf_name`, `bd_name`, `subnet_ip?`	Create a bridge domain
`aci_application_profile_create`	`tenant_name`, `app_name`, `description?`	Create an application profile
`aci_epg_create`	`tenant_name`, `app_name`, `epg_name`, `bd_name`	Create an EPG
`aci_contract_create`	`tenant_name`, `contract_name`, `description?`	Create a contract
`aci_contract_subject_create`	`tenant_name`, `contract_name`, `subject_name`, `filter_name`	Create a contract subject
`aci_filter_create`	`tenant_name`, `filter_name`, `description?`	Create a filter
`aci_filter_entry_create`	`tenant_name`, `filter_name`, `entry_name`, `protocol?`, `dst_port?`	Create a filter entry
`aci_epg_contract_provider_bind`	`tenant_name`, `app_name`, `epg_name`, `contract_name`	Bind EPG as contract provider
`aci_epg_contract_consumer_bind`	`tenant_name`, `app_name`, `epg_name`, `contract_name`	Bind EPG as contract consumer
`aci_epg_domain_bind`	`tenant_name`, `app_name`, `epg_name`, `domain_name`, `domain_type?`	Attach EPG to physical or VMM domain
`aci_subnet_create`	`tenant_name`, `bd_name`, `subnet_ip`, `scope?`	Add a subnet to a bridge domain

L3 Networking (6 tools)

Tool	Description
`aci_l3_outside_get()`	List all L3Outs
`aci_external_networks_get()`	List all external EPGs
`aci_bgp_peers_get()`	List all BGP peers
`aci_l3out_create`	Create a new L3Out
`aci_external_epg_create`	Create an external EPG under an L3Out

Advanced / Composite Operations (8 tools)

Tool	Description
`aci_vlan_pool_create`	Create a VLAN pool with encap block
`aci_physical_domain_create`	Create a physical domain and attach a VLAN pool
`aci_create_3tier_app`	Deploy a complete 3-tier app (Web/App/DB) with BDs, EPGs, filters, contracts
`aci_create_web_app_stack`	Deploy a web + app stack end-to-end
`aci_tenant_delete`	Delete a tenant (use with caution)
`aci_epg_delete`	Delete an EPG
`aci_contract_delete`	Delete a contract
`aci_get_operations_summary`	Return a structured list of all 50 operations

Available Transport Options

Mode	Description
`stdio`	Standard I/O — for local clients managed by VS Code, Claude Desktop, etc.

The server in scripts/server.py runs in stdio mode. VS Code manages the process lifecycle automatically via mcp.json.

Installation

Clone the repository and run the interactive setup script:

git clone <your-repo-url>
cd aci_mcp_devnet_submission
./setup.sh

The setup.sh script will:

Prompt for your APIC URL, username, and password
Write the credentials to scripts/.env
Install all Python dependencies via pip
Print instructions for starting the server

Alternatively, set up manually:

cd aci_mcp_devnet_submission
pip install -r requirements.txt

# Create scripts/.env manually:
cat > scripts/.env <<EOF
APIC_URL=https://<your-apic-ip>/
USERNAME=<your-username>
PASSWORD=<your-password>
EOF

Authentication

The server authenticates to the APIC using cookie-based session authentication (aaaLogin). Credentials are loaded from scripts/.env at startup.

scripts/.env format:

APIC_URL=https://10.x.x.x/
USERNAME=admin
PASSWORD=yourpassword

The server automatically re-authenticates when the APIC session token expires (HTTP 403), so long-running sessions stay connected without manual intervention.

Security note: The scripts/.env file is listed in .gitignore — never commit real credentials to source control.

Running the Server

Method 1: Direct Python (recommended)

cd scripts
python3 server.py

Method 2: Via setup.sh (first-time setup + run)

cd aci_mcp_devnet_submission
./setup.sh
# Follow prompts, then:
cd scripts && python3 server.py

Method 3: FastMCP dev mode (auto-reload on file changes)

cd scripts
fastmcp dev server.py

Usage Example: VS Code

GitHub Copilot in VS Code 2 has a built-in MCP client. Add the ACI MCP server to your VS Code mcp.json to use it directly from the Copilot chat window.

Step 1 — Add to mcp.json

Open your VS Code user mcp.json (Cmd+Shift+P → Open MCP Servers Configuration) and add:

{
  "servers": {
    "my-aci-mcp-server": {
      "type": "stdio",
      "command": "python3",
      "args": [
        "/absolute/path/to/aci_mcp_devnet_submission/scripts/server.py"
      ]
    }
  }
}

Replace /absolute/path/to/ with the actual path on your machine.

Step 2 — Start the Server

VS Code starts the server automatically when you open a Copilot chat session. You can also manually start/restart it from the MCP panel in the VS Code status bar.

Step 3 — Chat with your ACI Fabric

Open GitHub Copilot Chat (Cmd+Shift+I) and try natural language prompts:

📋 Query the fabric:

Show me all faults in the fabric

List the top 10 tenants

What is the current fabric health score?

🏗️ Provision policy:

Create a new tenant called "MyApp_Tenant"

Deploy a 3-tier application called "ECommerceApp" in tenant "Prod_Tenant"

Add a subnet 192.168.10.1/24 to bridge domain "app_bd" in tenant "Prod_Tenant"

🩺 Troubleshoot:

Show me all critical faults

Get all BGP peers in the fabric

List all endpoints currently learned in the fabric

The LLM will automatically select the right MCP tool(s), call the APIC REST API, and return structured results in the chat window.
